Sq/UC1918 Type Flat Line Common Mode Inductors
Productdetails:
| Plaats van herkomst: |
China |
| Merknaam: |
IKP |
| Certificering: |
CE/UL/REACH/ROHS |
| Modelnummer: |
IKP-LF-CMC-SQ1918 serie |
Betalen & Verzenden Algemene voorwaarden:
| Min. bestelaantal: |
1000 |
| Prijs: |
0.16-0.22 |
| Verpakking Details: |
karton |
| Levertijd: |
10-15 dagen |
| Betalingscondities: |
L/C, T/T |
| Levering vermogen: |
100,000/week |
Contact nu
Gedetailleerde productomschrijving
Basis informatie.
Model nr.
IKP-LF-CMC-SQ1918 serie
Werkfrequentie
Hoge frequentie
Structuur van de wikkeling
Verticale wikkeling van platte draad
Aard van de operatie
Verstoppingsspiraal
Structuur van de magnetizer
Ferriet spoel
Toepassingsgebied
EMI/EMC
Verpakkingsvorm
Verticaal/horizontaal
Inductiewaarde
Variabele inductor
Transportpakket
Karton en dienblad
Specificatie
SQ1918 serie
Productiecapaciteit
10000 stuks/dag
Productbeschrijving
Productkenmerken en -kenmerken:
*Groot platte draad wikkelingsproces
* Klein volume, grote stroom
*De eenheidstroomdichtheid is 1,3 maal of meer van die van een ronde koperdraad
*Lag DC-weerstand, kleine gedistribueerde capaciteit
* Makkelijk te verdwijnen
* Uitstekend EMI-effect en stabiliteit
* Geproduceerd door volledig automatische machine, hoge efficiëntie en stabiele kwaliteit
*Goede isolatievermogen en lange levensduur
*Verticaal of horizontaal, op maat beschikbaar
Elektrische parameters:
*Specificaties voor platte draden: breedte 1,0-2,0 mm, dikte 0,1-0,5 mm
*Nominale spanning ((v): 85 tot 265 AC, 50/60Hz
* Draaiverhouding: N1:N2=1:1
* Isolatieweerstand: 100mΩ MIN bij 500DC
*Testfrequentiereactie: 10 kHz 100 mV
*Temperatuurbereik: -40oCtot + 150oC
*Temperatuur stijging: 50oCMaximaal
* Gebruikt voor het absorberen van gemeenschappelijke modus interferentie signalen van 9-30MHz
*Gebruikt voor het absorberen van common mode signalen en differential mode signalen in de 9-30MHz band
Algemene productspecificaties:
| Specificatie |
Inductievermogen
Min.
1KHZ 0,25V |
Afmetingen (mm MAX) |
Stroom ((A) |
Vermogen ((W) |
| W |
D |
H |
L |
E |
1#Basis |
2#Basis |
Maximaal |
Maximaal |
| PIN 1 |
PIN 2 |
PIN 1 |
PIN 2 |
| SQ1515V15 |
>15 mH |
16 |
22 |
22 |
3.5 |
0.8 |
12.8 |
10 |
8 |
7 |
1.5 |
60 |
| SQ1515V20 |
>20 mH |
16 |
22 |
22 |
3.5 |
0.8 |
12.8 |
10 |
8 |
7 |
1.2 |
60 |
| SQ1515V25 |
>25 mH |
16 |
22 |
22 |
3.5 |
0.8 |
12.8 |
10 |
8 |
7 |
1.2 |
60 |
| SQ1515H15 |
>15 mH |
18 |
22 |
14 |
3.5 |
0.8 |
16.8 |
12.8 |
- |
- |
1.5 |
60 |
| SQ1515H20 |
>20 mH |
18 |
22 |
14 |
3.5 |
0.8 |
16.8 |
12.8 |
- |
- |
1.2 |
60 |
| SQ1515H25 |
>25 mH |
18 |
22 |
14 |
3.5 |
0.8 |
16.8 |
12.8 |
- |
- |
1.2 |
60 |
| SQ1615V15 |
>15 mH |
16 |
22 |
23 |
3.5 |
0.8 |
12.8 |
10 |
8 |
7 |
1.5 |
65 |
| SQ1615V20 |
>20 mH |
16 |
22 |
23 |
3.5 |
0.8 |
12.8 |
10 |
8 |
7 |
1.2 |
65 |
| SQ1615V25 |
>25 mH |
16 |
22 |
23 |
3.5 |
0.8 |
12.8 |
10 |
8 |
7 |
1.2 |
65 |
| SQ1615H15 |
>15 mH |
18 |
22 |
14 |
3.5 |
0.8 |
16.8 |
12.8 |
- |
- |
1.5 |
65 |
| SQ1615H20 |
>20 mH |
18 |
22 |
14 |
3.5 |
0.8 |
16.8 |
12.8 |
- |
- |
1.2 |
65 |
| SQ1615H25 |
>25 mH |
18 |
22 |
14 |
3.5 |
0.8 |
16.8 |
12.8 |
- |
- |
1.2 |
65 |
| SQ1918V12 |
>12 mH |
15 |
25 |
26 |
4 |
0.8 |
12.8 |
10 |
10 |
10 |
2.0 |
180 |
| SQ1918V20 |
>20 mH |
15 |
25 |
26 |
4 |
0.8 |
12.8 |
10 |
10 |
10 |
1.5 |
180 |
| SQ1918V30 |
>30 mH |
15 |
25 |
26 |
4 |
0.8 |
12.8 |
10 |
10 |
10 |
1.2 |
180 |
| SQ1918H12 |
>12 mH |
22 |
24 |
13 |
4 |
0.8 |
16.8 |
15 |
- |
- |
2.0 |
180 |
| SQ1918H20 |
>20 mH |
22 |
24 |
13 |
4 |
0.8 |
16.8 |
15 |
- |
- |
1.5 |
180 |
| SQ1918H30 |
>30 mH |
22 |
24 |
13 |
4 |
0.8 |
16.8 |
15 |
- |
- |
1.2 |
180 |
| SQ2418V12 |
>12 mH |
15 |
24 |
32 |
4 |
0.8 |
12.5 |
10 |
- |
- |
2.5 |
250 |
| SQ2418V20 |
>20 mH |
15 |
24 |
32 |
4 |
0.8 |
12.5 |
10 |
- |
- |
1.8 |
250 |
| SQ2418V30 |
>30 mH |
15 |
24 |
32 |
4 |
0.8 |
12.5 |
10 |
- |
- |
1.5 |
250 |
| SQ2418H12 |
>12 mH |
22 |
26 |
15 |
4 |
0.8 |
16.8 |
15 |
- |
- |
2.5 |
250 |
| SQ2418H20 |
>20 mH |
22 |
26 |
15 |
4 |
0.8 |
16.8 |
15 |
- |
- |
1.8 |
250 |
| SQ2418H30 |
>30 mH |
22 |
26 |
15 |
4 |
0.8 |
16.8 |
15 |
- |
- |
1.5 |
250 |
| SQ2724V07 |
>7 mH |
18 |
30 |
38 |
4 |
0.8 |
4 PINS |
- |
- |
3.5 |
280 |
| SQ2724V15 |
>15 mH |
18 |
30 |
38 |
4 |
0.8 |
4 PINS |
- |
- |
2.5 |
280 |
| SQ2724V20 |
>20 mH |
18 |
30 |
38 |
4 |
0.8 |
4 PINS |
- |
- |
1.8 |
280 |
| SQ2724H07 |
>7 mH |
25 |
31 |
18 |
4 |
0.8 |
16.8 |
16.8 |
- |
- |
3.5 |
280 |
| SQ2724H15 |
>15 mH |
25 |
31 |
18 |
4 |
0.8 |
16.8 |
16.8 |
- |
- |
2.5 |
280 |
| SQ2724H20 |
>20 mH |
25 |
31 |
18 |
4 |
0.8 |
16.8 |
16.8 |
- |
- |
1.8 |
280 |
| SQ2820V07 |
>7 mH |
16 |
30 |
38 |
4 |
0.8 |
4 PINS |
- |
- |
2.0 |
300 |
| SQ2820V20 |
>20 mH |
16 |
30 |
38 |
4 |
0.8 |
4 PINS |
- |
- |
2.5 |
300 |
| SQ2820V30 |
>30 mH |
16 |
30 |
38 |
4 |
0.8 |
4 PINS |
- |
- |
5.0 |
300 |
| SQ2820H07 |
>7 mH |
28 |
35 |
18 |
4 |
0.8 |
16.8 |
16.8 |
- |
- |
2.0 |
300 |
| SQ2820H20 |
>20 mH |
28 |
35 |
18 |
4 |
0.8 |
16.8 |
16.8 |
- |
- |
2.5 |
300 |
| SQ2820H30 |
>30 mH |
28 |
35 |
18 |
4 |
0.8 |
16.8 |
16.8 |
- |
- |
5.0 |
300 |
| SQ3126V081 |
>8mH |
22 |
34 |
38 |
4 |
0.9 |
18 |
16 |
- |
- |
8.0 |
400 |
| SQ3126V082 |
>8mH |
22 |
34 |
38 |
4 |
0.9 |
18 |
16 |
- |
- |
5.0 |
400 |
| SQ3126V10 |
>10 mH |
22 |
34 |
38 |
4 |
0.9 |
18 |
16 |
- |
- |
3.5 |
400 |
| SQ3126V25 |
>25 mH |
22 |
34 |
38 |
4 |
0.9 |
18 |
16 |
- |
- |
3 |
400 |
| SQ3126H081 |
>8mH |
28 |
35 |
18 |
4 |
1.0 |
20 |
16.8 |
- |
- |
8.0 |
400 |
| SQ3126H082 |
>8mH |
28 |
35 |
18 |
4 |
1.0 |
20 |
16.8 |
- |
- |
5.0 |
400 |
| SQ3126H10 |
>10 mH |
28 |
35 |
18 |
4 |
1.0 |
20 |
16.8 |
- |
- |
3.5 |
400 |
| SQ3126H25 |
>25 mH |
28 |
35 |
18 |
4 |
1.0 |
20 |
16.8 |
- |
- |
3 |
400 |
| SQ4391V12 |
>12 mH |
- |
- |
- |
- |
- |
- |
- |
- |
- |
7 |
600 |
| SQ4391H12 |
>12 mH |
28 |
45 |
16 |
4 |
1.0 |
39 |
21 |
- |
- |
7 |
600 |
*Aangepast is beschikbaar.
SQ-grootte van de magnetische kern en parameters van het magnetische circuit:
| Specificatie van de magnetische kern |
Grootte van de magnetische kern (na sproeiing) |
Parameters van de magnetische route |
| Een |
B. |
C |
D |
E |
F |
R |
Le(mm) |
Ae(mm2) |
Ve(mm3) |
C1 ((mm-1) |
| SQ12.5 x 12.5 x 4.8 |
12.8±0.4 |
12.8±0.4 |
5.2±0.3 |
5.2±0.3 |
8 ± 0.3 |
4.8 |
2.13 |
42.79 |
13.53 |
579.12 |
3.16 |
| SQ13 × 17,5 × 5 |
13.4±0.4 |
17.9±0.4 |
5.4±0.3 |
4.2±0.3 |
12.9±0.3 |
5.1 |
2.45 |
51.44 |
15.26 |
784.82 |
3.37 |
| SQ13.5 × 21.6 × 5 |
13.9±0.4 |
22 ± 0.4 |
5.3±0.3 |
4.1±0.3 |
15.6±0.3 |
5.3 |
2.7 |
55.60 |
15.90 |
874.50 |
3.50 |
| SQ15 × 15 × 5 |
15.5±0.4 |
15.5±0.4 |
5.3±0.3 |
5.8±0.3 |
10.9±0.3 |
5.3 |
2.65 |
48.98 |
14.48 |
709.22 |
3.38 |
| SQ15.5 × 18.6 × 5 |
16 ± 0.4 |
19 ± 0.4 |
6.3±0.3 |
4.5±0.3 |
13.8±0.3 |
6.5 |
3.4 |
53.20 |
15.34 |
816.09 |
3.47 |
| SQ16.3 × 15.5 × 6 |
16.6±0.4 |
15.8±0.4 |
6 ± 0.3 |
5.2±0.3 |
10.5±0.3 |
6.3 |
3.3 |
49.97 |
20.85 |
1041.86 |
2.40 |
| SQ17 × 20,6 × 6 |
17.3±0.5 |
20.9±0.5 |
6.3±0.3 |
5.7±0.3 |
14 ± 0.4 |
6.3 |
3.15 |
64.39 |
25.23 |
1624.80 |
2.55 |
| SQ17.5 × 24 × 6 |
17.8±0.5 |
24.5±0.5 |
6.3±0.3 |
6.2±0.3 |
18.9±0.4 |
6.3 |
3.15 |
68.80 |
22.22 |
1529.08 |
3.10 |
| SQ18.3 × 19.5 × 6 |
18.6±0.5 |
19.8±0.5 |
6.3±0.3 |
7.2±0.3 |
13.3±0.3 |
6.3 |
3.3 |
64.11 |
23.62 |
1514.10 |
2.71 |
| SQ18.3 × 20.8 × 6 |
18.6±0.5 |
20.9±0.5 |
6.3±0.3 |
7.4±0.3 |
14.5±0.4 |
6.3 |
2.9 |
65.86 |
23.46 |
1545.21 |
2.81 |
| SQ18.6 x 15.6 x 6.8 |
19 ± 0.4 |
16 ± 0.4 |
6.6±0.3 |
6.0±0.3 |
13 ± 0.3 |
7 |
3.55 |
51.26 |
22.65 |
1161.11 |
2.26 |
| SQ20 x 22.5 x 6.8 |
20 ± 0.5 |
22.8±0.5 |
6.6±0.3 |
7.4±0.3 |
15.2±0.4 |
6.9 |
3.6 |
72.10 |
30.20 |
2177.01 |
2.39 |
| SQ20x29x6.3 |
20.3±0.5 |
29.3±0.5 |
6.6±0.3 |
7.7±0.3 |
22.2±0.4 |
7 |
3.55 |
83.90 |
31.46 |
2639.81 |
2.67 |
| SQ26 × 31 × 9 |
26.3±0.5 |
31.8±0.6 |
9.3±0.4 |
9.7±0.4 |
22.7±0.4 |
9.3 |
4.65 |
96.56 |
54.21 |
5234.96 |
1.78 |
