Specifications:
• Power range:500VA to 10000VA
• Phase: Single
• Input / Output: Customized
• Insulation Class: UL class B, F, H, N (optional)
• Isolation: 4KV (Hi-pot)
• Easy to change diameter and height of the core
• Customized specifications are welcome
|
Rated Power
(VA)
|
Outside Dimension
D*H(mm)
|
Weight
(kg)
|
Temp. Rise
(℃)
|
Approval |
| 500 |
145*65 |
5.5 |
52 |
UL/CE/RoHS/CQC |
| 1000 |
175*85 |
8.5 |
54 |
UL/CE/RoHS/CQC |
| 2000 |
210*90 |
14.7 |
55 |
UL/CE/RoHS/CQC |
| 2500 |
210*100 |
16.7 |
56 |
UL/CE/RoHS/CQC |
| 3000 |
215*105 |
17.7 |
57 |
UL/CE/RoHS/CQC |
| 3500 |
230*115 |
21.8 |
58 |
UL/CE/RoHS/CQC |
| 5000 |
290*115 |
30.0 |
59 |
UL/CE/RoHS/CQC |
| 7000 |
330*115 |
35.0 |
62 |
UL/CE/RoHS/CQC |
| 10000 |
360*115 |
45.0 |
65 |
UL/CE/RoHS/CQC |
◆We can design and manufacture customized part with specific requirement
